Harness Taping Bundling Packaging Machines

WraoLiner-40 Plus

Floor-standing model for consistent harness taping Taping Machines

Floor-standing model for consistent harness taping Taping Machines

The LT-25 Floor-Standing Wire Harness Taping Machine is designed for high-efficiency taping of large and complex wire harnesses. It ensures consistent wrapping with a smooth finish, making it ideal for automotive, appliance, and industrial wiring applications. Its manual winding control allows flexibility for different harness lengths, while the adjustable speed ensures optimal taping quality.

  • Wide Diameter Range: Supports wire harnesses from 8 mm to 35 mm.Unlimited Winding Length: Manual control for any harness length.Multi-Tape Compatibility: Works with PVC, velvet, and acetic acid tapes (without release paper).

  • Customizable Tape Reel Inner Hole: Available in 38 mm, 32 mm, or special sizes upon request.Adjustable Speed: 130–400 RPM for precise taping requirements.Dual Voltage Operation: Compatible with 100–240 V AC power supply.

An Affordable Excellence Machine

This standard crimp machine is designed for crimping terminals using quick change applicators and for using both at the same time, in one single operation.

Highlights

Wide Diameter Range

Wide Diameter Range

Handles 8–35 mm harnesses.

Unlimited Winding Length

Unlimited Winding Length

Manual control, no limits.

Multi-Tape Compatibility

Multi-Tape Compatibility

Works with PVC, velvet, acetate.

Adjustable Speed

Adjustable Speed

130–400 RPM flexibility.

Technical Specifications

  • Model

    WraoLiner-40 Plus

  • Usage

    Wire Harness Taping

  • Applicable Wire Diameter

    8 – 35 mm

  • Winding Length

    Unlimited (Manual Control)

  • Tape Type

    PVC / Velvet / Acetic Acid (no release paper)

  • Tape Reel Inner Hole

    38 mm / 32 mm / Customized (inform size)

  • Applicable Tape Size

    Width 10 – 25 mm, OD ≤ 110 mm

  • Winding Speed

    130 – 400 RPM

  • Power Supply

    AC 100 – 240 V, 50/60 Hz

  • Dimensions (L×W×H)

    400 × 350 × 250 mm

  • Weight

    4 kg

Processing Capabilities

Cutting to length

Full stripping

Ferrule crimping

Cutting pulled strands / Zero cut

Partial stripping

Wire end solidifying, splicing, welding

Get the full product details

You can explore features, Specifications and benefits in our brochure. Our brochure provides insights into cutting-edge automation solutions designed to boost efficiency, precision, and performance.
