Cutting Stripping Machines

PrimeTwist-600

Automatic Cable Cutting & Stripping & Twisting Machines For cable sizes up to 6 sq.mm

Automatic Cable Cutting & Stripping & Twisting Machines For cable sizes up to 6 sq.mm

Fully automatic cutting, stripping, and twisting of 0.1–6mm² wires. Ideal for automotive and appliance wire harnesses, improves speed, and saves labor.

  • Fully automated and easy to use, compatible with various cables for high efficiency.

  • Boosts speed and reduces labor in electronics and automotive industries.

An Affordable Excellence Machine

This standard crimp machine is designed for crimping terminals using quick change applicators and for using both at the same time, in one single operation.

Highlights

Fully Automated Operation

Fully Automated Operation

Simplifies processes for maximum efficiency.

High-Speed & Easy to Use

High-Speed & Easy to Use

Boosts productivity with user-friendly control.

Supports Various Cable Types

Supports Various Cable Types

Flexible for diverse industrial needs.

Reduces Labor Costs

Reduces Labor Costs

Ideal for electronics and automotive applications.

Technical Specifications

  • Model

    PrimeTwist-600

  • Wire Cross Section

    0.2 – 6.0 mm²

  • Features

    One wire stripping & twisting

  • Electrical Connection

    110V / 220V, 50Hz / 60Hz

  • Power

    300 W

  • Operation Interface

    4.3/6 inch C Touch screen display

  • Machine Dimension

    460 × 470 × 325 mm

  • Wire Length Range

    1 – 9999 mm

  • Strip Length

    Front end: 0 – 30 mm; Rear end: 0 – 8 mm

  • Length Accuracy

    ±(0.002 × L) mm

  • Intermediate Peeling Times

    16 times

  • Max Conduit Inside Diameter

    6 mm

  • Wire Material

    PVC, Teflon, Braided, Fiberglass wire

  • Blade Material

    Hard tungsten steel

  • Transport Speed

    (L = 100 mm) 4000 – 5000 pieces/hour

  • Driving Mode

    Four-wheel drive (silent hybrid stepper motor, 0.1 mm forward per step)

Processing Capabilities

Cutting to length

Full stripping

Ferrule crimping

Cutting pulled strands / Zero cut

Partial stripping

Wire end solidifying, splicing, welding
